DAC4350CT Single Phase 4P Multi-function with Relay 4G Communication DIN rail Electric

1.Max 100A DC.

2. Standard 2-modulus width, TH35-7.5 type rail installation

3.Touch key design improves the operation of the keys and reduces the key failure rate.

4.Multi-function parameter measurement for voltage, current, active power, reactive power, apparent power, power factor, and phase angle

5.Provide total harmonic content analysis data of voltage and current

6.Support two-way energy metering, providing monthly electricity consumption statistics for the last 12 months, and daily electricity consumption statistics for the last 31days

7.Support dual timing of meter start up running time and load running time

8.Support 4G Communication

9.Support access of two rate switching signals and realize power metering of two rates

10.Support 1 passive pulse output, 1 RS485 communication, Baud rate up to 38400bps, support Modbus RTU, DL/T645-2007 protocol

Contact now Ask a question

Product parameters

Technicial parameters

Model	DAC4350CT
Electrical Characteristics	Supply voltage	85 to 300 V AC or 120 to 420 V DC
	Power consumption	< 4VA/0.5W
	Rate voltage (Un)	3110/190V or 3230/400V AC
	Operational voltage	L-N: 30 - 350V AC; L-L: 30 - 500V AC
	PT1 (Primary)	30 - 500000V
	Impedance of voltage measures circuit	1MΩ
	Overload capacity of voltage	2*Un for 1 second
	Rate current(Ib)	5A
	Maximum current(Imax)	6A
	Operational current	0.1%Ib to Imax
	CT1 (Primary)	1 to 9999 A
	Impedance of current measures circuit	<0.01 ohm
	Overload capacity of current	20*Imax for 0.5 second
	Operational frequency range	45 - 65Hz
	Pulse constant	5000imp/kWh
	Display	LCD with backlight
	Maximum reading of energy	99999999 MWh/MVarh
	Measure type	Three phase four wire, Three phase three wire,Single phsae two wire
Measurement accuracy	Voltage, Current	±0.5%
	Active power	±0.5%
	Reactive power	±2.0%
	Apparent power	±0.5%
	Active energy	±0.5%
	Reactive energy	±2.0%
	Power factor	±0.5%
	Frequency	±0.1%
	Harmonic distortion	±2.0%
Environmental Characteristics	Operating Temperature	-25 to +55ºC
	Storage Temperature	-40 to +80ºC
	Humidity	< 90%, non-condensing
	Pollution Degree	2
	Altitude	Up to 2000m
	Vibration	10 Hz to 150Hz, IEC 60068-2-6
	IP Degree of Protection	Designed to IP51 front display, IP30 meter body
Electromagnetic Characteristics	Electrostatic Discharge	±8kV(contact discharge),±15kV(air discharge)
	Immunity to Radiated Fields	10V/m,80 - 2000MHz
	Immunity to Electrical Fast Transients	±4kV
	Immunity to Surges	±4kV
	Immunity to Conducted Disturbances	10V,0.15 - 80MHz
	Immunity to Magnetic Fields	IEC 61000-4-8
	Immunity to Voltage Dips	IEC 61000-4-11
	Radiated Emissions	Class B, according EN55011
	Conducted Emissions	Class B, according EN55011
	Harmonics Emissions	IEC 61000-3-2
Safety	Overvoltage Category	CAT III, according IEC 61010-1
	Measurement Category	CAT III, according IEC 61010-1
	Insulation	AC Voltage Test: 4kV for 1 minute
	Insulation	Impulse Voltage Test: 6kV - 1.2/50µS waveform
	Protective Class	II, according IEC61010-1
Communications	Interfaces standard and protocols	2-wire RS485, Modbus RTU Optional: Mbus
	Buad rate	1200 to 38400 bps, default is 9600 bps
	Parity bit	None, Even, Odd, default is None
	Stop bit	1 or 2, default is 1
	Response time	<100ms
	Transmission mode	half-duplex
	Transmission distance	Up to 1000m
	Max. Bus loading	64 pcs
Pulse output	Interface type	Open collector optocoupler
	Pulse constant	Per pulse equal 0.001/0.01/0.1/1 kWh/kvarh (Configurable)
	Pulse width	60/100/200 milliseconds (Configurable), default is 100milliseconds
	Pulse output type	Import/export/total active energy, Import/export/total reactive energy (Configurable)
	Class	Class A, according IEC 62053-31
	Input voltage	5 to 27 VDC
